The Sinus-500PRO 500VA uninterruptible power supply is designed for emergency power supply of devices that require operation in the event of a power outage in the electrical network. The device features an intelligent 3-stage battery charging algorithm and 3 independent charging current levels depending on the battery size (3A, 7A, 10A).
In the event of power outage detection, the inverter switches to "emergency power" mode, drawing energy previously stored in the battery. The switch from battery power to the grid occurs automatically when voltage appears in the network with simultaneous recharging of the battery. The inverter is designed to power inductive motors, allowing it to be used to power refrigerators, heating pumps, stoves, etc. Sinus-600PRO serves as a voltage stabilizer AVR (Automatic Voltage Regulation).
The inverter is designed to power inductive motors, allowing it to be used to power refrigerators, heating pumps, stoves, etc.
All functions are included in one device:
• pure sine wave DC/AC inverter
• UPS emergency switch - switching power source from the grid to the battery
• intelligent 3-stage network battery charger (rectifier) charging the battery with safe current
• AVR voltage stabilizer
Device features:
• Processor control of output shape and voltage
• Protections against overload, short circuit, and thermal
• Indication of too low and too high voltage supply and deep discharge state of the battery
• Intelligent smooth fan control
• High efficiency
• Low power consumption without load
• Guaranteed quality and reliability
Included:
• Sinus-500PRO 500VA 12V/230V UPS with AVR function
• Power cables for the battery
• User manual in Polish
• Warranty card - 3 years warranty
| Specification | |
| Input voltage: | 140÷275V |
| Output voltage: | 230 V |
| Maximum power: | 600W |
| Continuous power: | 350W |
| Output voltage waveform: | Sine wave |
| Input voltage frequency: | 45÷65Hz |
| Output voltage frequency: | grid supply - in accordance with the grid frequency 45÷65Hz |
| Output voltage frequency: | battery supply - 50Hz |
| Switching time: | |
| Soft start for inductive motors: | YES |
| Overload protection: | YES |
| Short circuit protection: | YES |
| Protection against power polarity reversal: | YES |
| Thermal protection: | 80°C |
| Power supply voltage range protection: | 120-275 VAC |
| Audible alarm: | YES |
| Cooperation with power generators: | YES |
| Battery charging current: | 3A / 7A / 10A |
| Warning before battery discharge: | YES |
| Operating temperature: | -10°C ~ +40°C |
| Efficiency: | >97% |
| Cooling: | Active |
| Power connector: | Power cable with 230VAC plug |
| 230V output socket: | 1 x E (with pin) |
| Housing: | Aluminum |
| Protection degree (IP): | IP21 |
| Dimensions: | 140 x 180 x 350 mm |
| Weight: | 5.2 kg |
| Warranty: | 3 years |
