Uni-T UT12D non-contact voltage tester - A device that allows you to safely detect voltage. These types of indicators are commonly used in work related to the repair or maintenance of wires, sockets and other electrical and electronic devices. The meter allows you to detect alternating voltage in the range from 24 V to 1000 V. The tester is able to detect voltage in wires running under plaster. This is a very useful function during renovation work, when we need to drill a hole in the wall where such wires may be located. Voltage detection is signaled by a built-in buzzer and flashing LEDs.
Key product features
The meter can work in two modes. The first is the low-voltage mode used to measure devices such as low-voltage motors (below 90 V), audio systems, arc welders, mining lighting, and wires with a thick insulating layer. The second is the high voltage mode, which is used to measure, m.in, three-phase systems (from 90 V to 1000 V), electrical panels, power distribution units or electrical equipment operating with high voltage. The device is powered by two AAA batteries and is equipped with an automatic power off function. An additional advantage of the UT12D is the flash that allows you to freely take measurements in places with low light conditions. Thanks to its durable housing, the device is resistant to damage that can occur when falling from a height of about 1 meter.
Technical specifications:
- AC Voltage - Low Range: 24 V to 1000 V
- AC Voltage - High Range: 24V to 1000V
- Frequency range: 50 Hz to 60 Hz
- Low supply voltage indication: below 2.4 V
- Power supply: 2 x AAA 1.5 V batteries (included)
- Dimensions: 150 mm x 19 mm x 23 mm
- Weight: 50 g
- Tester UT12D
- bateria 2x 1,5V AAA
- 2x AAA
- 150 mm x 19 mm x 23 mm
- 50
- Tester UT12D
- bateria 2x 1,5V AAA
- 2x AAA
- 150 mm x 19 mm x 23 mm
- 50
